Safety Bar HP EVO
SAFETY BAR HP EVO is an industrial LED lamp designed for the safety lighting of overhead cranes. It is ideal for enhancing the safety of operators and workers in surrounding maneuvering areas, particularly in noisy and hazardous environments.
SAFETY BAR HP EVO is an industrial LED lamp designed for the safety lighting of overhead cranes. It is ideal for enhancing the safety of operators and workers in surrounding maneuvering areas, particularly in noisy and hazardous environments.
Mounted on the overhead crane, SAFETY BAR HP EVO projects a blue, red, green, or yellow beam of light onto the ground, providing a visual warning of the crane’s approach and marking the front and rear maneuvering areas.
SAFETY BAR HP EVO is made with high-efficiency LEDs and a lens with a focusing optic. The device features an integrated fan for optimal thermal dissipation management. The materials used, such as anodized aluminum and stainless steel, make the SAFETY BAR HP EVO a durable and high-quality product.
Information
No technical details available
Technical Details
Code | SAFETY BAR HP EVO BLUE LC0117N | SAFETY BAR HP EVO RED LC0118N |
Alimentation | 90-305Vac / 50-60Hz | 90-305Vac / 50-60Hz |
Maximum Absorbed Power | 65W | 50W |
Source | n°3 HIGH POWER BLUE LED | n°3 HIGH POWER RED LED |
Projected Shape | Bar | Bar |
Dominant Wavelength | 460nm (Blue) | 620nm (Red) |
Operating Temperature | -40°C to +60°C | -40°C to +50°C |
Control | On/Off | On/Off |
Materials | Anodized extruded aluminum (structure), Painted steel (brackets), Stainless steel (screws and cable glands), Glass (lenses), EPDM (gaskets), PVC (lens closure). | Anodized extruded aluminum (structure), Painted steel (brackets), Stainless steel (screws and cable glands), Glass (lenses), EPDM (gaskets), PVC (lens closure). |
IP Protection class | IP65 | IP65 |
Impact Resistance Grade IK | IK08 | IK08 |
Photobiological Risk Class | RG1 | RG1 |
Weight | 4,2 Kg | 4,2 Kg |
Packaging Dimensions | 300mm (L) x 285mm (W) x 230mm (H) (2 lamps per box) | 300mm (L) x 285mm (W) x 230mm (H) (2 lamps per box) |
Lamp dimensions | 260mm (L) x 65mm (W) x 240mm (H) | 260mm (L) x 65mm (W) x 240mm (H) |
No technical details available
