RGT EI(1) 45 – EI(2) 60 – EW 120

Standby hero. Instant guardian. Gravity-failsafe fire shutters – waiting silently, acting decisively when every second counts.

Certification tested in accordance with EN 1634-1 and EN 1634-3 classified according to EN 13501-2 validated cycle test in accordance with C2 (> 10.000 cycles) CE marked in accordance with EN 13241 and EN 16034 Application only suitable for indoor / indoor situations only to be used in case of calamity (‘waiting’ function) mounting possible on and in the wall / opening permissible mounting surfaces include: aerated concrete, sand-lime brick, concrete, masonry, fire-resistant steel construction Standard gravity failsafe tubular motor 230 V incl. control box optical / acoustic signaling galvanized steel side guides and cover box
RGT EI(1) 45 – EI(2) 60 – EW 120RGT EI(1) 45 – EI(2) 60 – EW 120

Technical Specifications

SpecificationValue
classificationEI(1) / EI(2) / EW
fire resistance45 / 60 / 120 mins
max width7m
max height7m
max opening35m2

Features
